Qingdao chenyu union valve is a China valve reliable vendor,our main product contains butterfly valve,globe valve, gate valve, angle valve, check valve, ball valves..
Qingdao chenyu union valve has the ABS,BV,LR,DNV class approval.
We can provide you a valve sample if you need.
Main Materials
| Name | Material |
| Body | Cast Iron Ductile Iron Carbon Steel Stainless Steel AL-Bronze |
| Disc | Ductile Iron Carbon Steel Stainless Steel AL-Bronze |
| Shaft | Stainless Steel Monel K500 |
| Seat | BUNA NBR EPDM VITON PTFE HEPDM Neoprene Hypalon Natural rubber |
Technical Parameters:
| Size | DN32-DN600 | DN650-DN2000 |
| Working pressure | 16Bar | 10Bar |
| Shell | 24Bar | 15Bar |
| Seal(Air) | 6Bar | 6Bar |
| Operating Temperature | -45ºC~+150ºC | |
| Operating Environment | Ballast and bilge system Chemical processing | |
| Desalination plants Drilling rigs Drinking water | ||
| Dry powder Food and beverage Gas plants | ||
| HAVC Mining industry Paper industry Sand handling Seawater Sugar industry | ||
| Thermo technical water treatment Waste water | ||
| Driving method | Hand Lever Worm Gear Electric Pneumatic | |
